Offshore pipes for oil and gas

Thermal Insulation reinvented

Kingspan LOGSTOR deliver high performance Thermal Insulation to the Oil & Gas industry. Starting from a long experience in delivering to the market highly efficient insulated pipelines for shallow water, our offshore solutions range is now extended to the deep water horizon where we have reinvented end-to-end thermal insulation with innovative composite systems based on Polymer Alloys.

We focus on supplying durable and efficient thermal insulation solutions for both shallow and deep water offshore pipelines. Our strong R&D commitment has driven us to develop advanced systems that reflects our identity.

For shallow water conditions, the LOGSTOR SinglePipe is a proven solution with long track-record. The system combines the high insulation performance of the PUR foam and the strength of the Polyolefin high density casing where each pipe is individually encapsulated with a unique sealant or Plastic welding at the extremity.

The new C-PiPe range allows LOGSTOR to deliver insulation systems for any water depth. Our composite solutions combine the anti-corrosion properties of the epoxy and the easiness of application of the Polyurethanes. The best of both worlds!

All of our systems have suitable field joint coatings and can be laid by all methods including pipe reeling. Today we rate our system for operation temperature up to 120°C and our next developments will bring our expertise to serve temperature over 180°C

Contact

KIM SCHACHT
Technical Director, LOGSTOR Thermal Solutions

Kim.Schacht@kingspan.com
Mob.: +45 9966 1163

SinglePipe® 85 SW

The LOGSTOR SinglePipe® 85 SW is a shallow water thermal insulation solution for offshore pipelines able to sustain depths up to 340 meters. The system is designed to be cost-effective and can be installed with any pipe-laying method.

SinglePipe® 120 SW

The LOGSTOR SinglePipe® 120 SW is a shallow water HT thermal insulation solution for offshore pipelines able to sustain depths up to 340 meters. The system is designed to be cost-effective and can be installed with any pipe-laying method.

C-PiPe® 95 DW

The LOGSTOR C-PiPe® 95 DW is a deep water thermal insulation solution for offshore pipelines able to sustain any water depths. The system is developed for a mobile plant, optimal logistic and rapid production method. It can be installed with any pipe-lay method.

C-PiPe® 120 DW

The LOGSTOR SinglePipe® 120 DW is a deep water HT thermal insulation solution for offshore pipelines, able to sustain any water depth. The system is designed to be cost-effective and can be installed with any pipe-laying method.

Pipe-in-Pipe sliding system

The LOGSTOR Pipe-in-Pipe offshore hot applications solution consist of steel inner pipe, steel outer pipe (with corrosion protection), and PUR foam bonded onto the inner pipe.
The outer pipe is able to slide on the insulation.

Pipe-in-Pipe bonded system

The LOGSTOR Pipe-in-Pipe offshore hot applications solution consist of steel inner pipe, steel outer pipe (with corrosion protection), and PUR foam injected between the two pipes.
A bonded pipe insulation system for subsea applications.
